HP Smart Array errors 104
P840 controller LEDs
Immediately after you power up the server, the controller runtime LEDs illuminate briefly in a predetermined
pattern as part of the POST sequence. At all other times during server operation, the illumination pattern of
the runtime LEDs indicates the status of the controller.
Item Color Name Interpretation
1
Green Heartbeat When the controller is in good health, this LED flashes at 1 Hz.
During power up, this LED is solid for up to 2 seconds.
2
Amber Fault When an error occurs, this LED is on. During power up, this LED
is solid for up to 2 seconds.
3
Green Crypto On = All attached volumes are encrypted.
Off = All attached volumes are plaintext.
Flashing = Both encrypted and plaintext volumes are present.
