HPE StoreOnce 4700 24 TB Backup
The following table contains the spare parts for the main components in the server unit. See the
HPE StoreOnce 4500/4700 (24 TB) and 4500 (48TB) Expansion Module (page 9) for information
about the hard disks in the storage expansion shelf and the SAS cabling from the server unit to
the expansion shelf.
NOTE: The disks in the server unit are different from the disks in the expansion shelf. Be sure
to order the correct replacement disk for the location where the disk has failed.
This is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the
online source, use the feedback form to log the problem: http://partsurfer.hpe.com/
ContactUs.aspx.
Table 2 HPE StoreOnce 4700 24TB Backup spares part numbers (SPN)
SPNDescriptionPart
670521-001Intel Xeon E5-2690 Eight-Core 64-bit processor
- 2.90GHz. See note at the end of this table.
Processor (two per system)
730235-001Intel Xeon E5-2680v2 Ten-Core 64-bit processor
- 2.8-GHz. See note at the end of this table.
Processor (two per system)
662522-001Standard efficiency heatsinkProcessor Heatsink
660185-0011200 W, Platinum Plus, 94%Power supply (two per system)
662530-001System I/O boardMotherboard
664691-0018GB, 1600MHz, PC3-12800R-11, DDR3-1600,
Single-Rank, 1.5V, Dual In-Line Memory Module
(DIMM)
Memory DIMM (16 x 8 GB, eight per
processor)
653954-0011TB, 7,200 rpm, SFF, 6G, dual portHard disk (two in the server unit)
832984-0011TB, 7,200 rpm, SFF, 12G, dual port
634025-001SPS-BD ETHERNET 1Gb 4P 331FLR ADPTR1Gbit FlexLOM Ethernet Controller
698465-001ASSY, PCA 4i/4eRAID controller p1224 (two per system)
729358-001CBL, ASSY, MINI SAS HD to MINI SAS, InternalInternal SAS cable (one per RAID card)
660093-001ASSY, CA/CAPACITOR,36",FLSuperCapacitor (one per RAID card)
633542-001PCA, DDR3 MINIDIMM MOD 244P 1Gx72RAID cache (one per RAID card)
489191-001( FC SFP =
468508-001)
HP 8Gb Dual Channel PCI-e to Fibre Channel
Host Bus Adapter
Fibre Channel card (two per system)
615406-001HP NC552SFP Dual Port 10GbE Server Adapter10 GbE card (one per system)
800611-001SPS-BD RISER STORAGEPCIe riser card PCA.
More information
(page 7)
6 Part numbers for replacement parts
