HPE StoreOnce 4500/4700 (24TB) and 4500 (48TB) Expansion Modules
The two HPE StoreOnce Expansion Modules use the same storage enclosure, but their hard
drive capacity is different. The StoreOnce 4500/4700 (24TB) Expansion Module contains twelve
2TB hard disks. The StoreOnce 4500 (48 TB) Expansion Module contains twelve 4TB hard disks.
NOTE: The disks in the server unit are different from the disks in the expansion shelf. Be sure
to order the correct replacement disk for the location where the disk has failed.
This is an offline list, created from partsurfer. If there is a problem with these Spares Part Numbers,
check the online source at: http://partsurfer.hpe.com/search.aspx. If the problem exists in the
online source, use the feedback form to log the problem: http://partsurfer.hpe.com/
ContactUs.aspx.
Table 4 HPE StoreOnce 4500/4700 24TB Capacity Upgrade Kit spares part numbers
SPNrDescriptionPart
519325-001Fan assembly for HP D2700 and D2600 Disk EnclosureFan module
511777-001Hot-plug power supply—460 watts, high efficiency (HE),
common slot
Power supply (two per unit)
519316-001Controller board—SAS, Input-Output (I/O) moduleI/O module
519317-001Backplane board for HP D2600 Disk Enclosure—includes
12 slots for Serial Attached SCSI (SAS) disks
Hard disk backplane
743403-0012TB 6G SAS MDL HDDHard disks (12 per 4500/4700 24TB
unit)
743405-001SPS-DRV HD 4TB 6G 7.2K 3.5 SAS MDL STORHard disks (12 per 4500 48TB unit)
717429-001SPS-CA EXT HYB MSAS HD TO MSASSAS cable, from RAID controller to
the first shelf (and second shelf to
second RAID controller for 4700)
408765-001SPS-CA,EXT MINI SAS, 0.5MSAS cable, from expansion shelf to
expansion shelf
HPE StoreOnce 4500/4700 (24TB) and 4500 (48TB) Expansion Modules 9
