HP XP7 User Manual

DescriptionItem
1. The control information used by the storage system, such as control cylinders, is not included in the Free capacity.
2. The total capacity of the LDEVs and the Free capacity is displayed in the Total.
Parity Groups tab
DescriptionItem
Parity group identifier of the parity group in the storage system.Parity Group ID
Status of each LDEV in the parity group.LDEV Status
Normal: Normal status.
Blocked: Host cannot access a blocked volume.
Warning: Problem occurs in the volume.
Formatting: Volume is being formatted.
Preparing Quick Format: Volume is being prepared for quick formatting.
Quick Formatting: Volume is being quick-formatted.
Correction Access: Access attribute is being corrected.
Copying: Data in the volume is being copied.
Read Only: Data cannot be written on a read-only volume.
Shredding: Volume is being shredded.
Hyphen (-): Any status other than the above.
RAID level. An asterisk "*" indicates that the parity group to which the LDEV
belongs is interleaved (concatenated). Either RAID level of the parity group
appears.
RAID Level
Emulation type of each parity group.Base Emulation Type
Capacity
• Free: Capacity of the free space of each parity group. The control information
used by the storage system, such as control cylinders, is not included in the
Free capacity.
• Total: The total capacity of the LDEVs and Free capacity is displayed in the
Total.
Number of LDEVs
• Unallocated: Number of unallocated LDEVs in each parity group.
• Total: Total number of LDEVs in each parity group.
Drive type and rpm in use on this LDEV.Drive Type/RPM
Encryption information.Encryption
Enable: encrypted parity group
Disable: non-encrypted parity group
If the parity group in which the encryption setting is not defined, a hyphen (-) is
displayed.
Displays the attribute of the parity group.Attribute
Hyphen (-): The parity group in which the attribute is not defined.
Resource group name and ID of which this parity group is a member.Resource Group Name (ID)
Parity Groups window 251
