HP XP7 User Manual

LUN Properties window
LUN Properties table
This table provides information about the selected LUN.
DescriptionItem
Identifier of the selected logical unit.LUN ID
LDEV identifier, which is the combination of LDKC, CU, and LDEV.LDEV ID
Name of the LDEV.LDEV Name
Name of the host group.Host Group Name
The host mode of the host group.Host Mode
The number of host mode options that are enabled.Host Mode Option
Identifier of the port on this volume.Port ID
Emulation types for the logical volume (or logical device).Emulation Type
Size of the logical volume.Capacity
Provisioning type assigned to this logical volume.Provisioning Type
Basic: Internal volume.
External: External volume.
THP: V-VOL of Thin Provisioning.
Snapshot: Fast Snap volume.
Displays the attribute of the LDEV.LDEV Attribute
Command Device: Command device.
Remote Command Device: Remote command device.
LUN Properties window 423
