Port tree
Use this tree to find information about user authentication on each port. When you select a port
from this tree, the Authentication Information (Target) list on the right provides user information of
the hosts that are registered on the port. In addition, the Authentication Information (Host) list below
the Authentication Information (Target) list provides the user information of the selected port.
Double-click the Fibre folder to view all fibre channel ports in the storage system. The Fibre folder
is available only if the storage system contains a fibre channel adapter. Double-click the fibre
channel ports to view host groups in that port. The host group name appears beside the icon.
DescriptionItem
Indicates a fibre channel port.
CLX-Y
Indicates that the host group performs authentication of hosts.
host group name
Indicates that the host group does not perform authentication of hosts.
host group name
Authentication information (target) list
The list on the right provides user information of the host groups that are allowed to connect to the
port or host group specified in the tree.
DescriptionItem
Names of the host group.Group Name
User name of the host group. When the user name is not defined for a host group, this column
is blank.
User Name
Indicates whether to perform user authentication for the host.Authentication
• Enable: The host is a target of user authentication.
• Disable: The host is not a target of user authentication.
Authentication window 427
