For Smart Tiers or Smart Tiers Z pools
When you create a Smart Tiers or Smart Tiers Z pool, the following table displays.
Pool Configuration Patterns table
DescriptionItem
Displays the priority of the pool configuration.Priority
Displays whether the pool configuration is selected or not.Selected
Displays the total capacity of the poolTotal Capacity
Displays the tier 1 information.Tier 1
Drive Type/RPM: Displays the data drive type and RPM of pool-VOLs.
RAID Level: Displays the RAID level of pool-VOLs.
Rate (%): Displays the percentage of the tier 1 against the total capacity of the
pool.
Displays the tier 2 information.Tier 2
Drive Type/RPM: Displays the data drive type and RPM of pool-VOLs.
RAID Level: Displays the RAID level of pool-VOLs.
Rate (%): Displays the percentage of the tier 2 against the total capacity of the
pool.
Displays the tier 3 information.Tier 3
Drive Type/RPM: Displays the data drive type and RPM of pool-VOLs.
RAID Level: Displays the RAID level of pool-VOLs.
Rate (%): Displays the percentage of the tier 3 against the total capacity of the
pool.
If the pool configuration is changed, select a row in the Pool Configuration
Patterns table. Then click this button. The selected pool configuration is reflected
to the pool setting.
Select
364 Thin Provisioning and Smart Tiers GUI reference
