DescriptionItem
Opens the Remove Hosts window.Remove Hosts
Opens a window where you can export configuration information listed in the
table to a file that can be used for multiple purposes, such as backup or reporting.
Export
Ports tab
This tab provides information about the ports assigned to the logged-on user.
DescriptionItem
Identifier of the port. Clicking a port ID opens Port/Host Groups: Host Groups
and Hosts tabs.
Port ID
WWN of the port.Internal WWN
Data transfer speed for the selected fibre channel port in the unit of Gbps (Gigabit
per second).
Speed
Valid speeds are 2, 4, 8, 10, or 16 Gbps. If Auto is set for the port speed, Auto
(2, 4, 8, 10, or 16 Gbps) appears. The value enclosed in parentheses is defined
by the storage system. A hyphen (-) appears in the parentheses when the
connection is not in the linkup status.
LUN security setting (Enabled or Disabled) on the port.Security
Type of the port.Type
Address of the port.Address (Loop ID)
Indicates whether a fabric switch is used.Fabric
Topology of the port.Connection Type
Attribute of the port indicating I/O flow.Attribute
• Initiator: Issues I/O commands to a target port when I/O is executed between
storage systems with Continuous Access Synchronous, and so on.
• Target: Receives I/O commands from a host.
• RCU Target: Receives I/O commands from an initiator when I/O is executed
between storage systems with Continuous Access Synchronous, and so on.
• External: Issues I/O commands to a target port of an external storage system
with External Storage.
Resource group names and IDS of the portsResource Group Name (ID)
The static MAC address assigned by the FCoE controller.ENode MAC address*
Unique identifier of the VLAN.VLAN ID*
Dynamic MAC address assigned by the FCoE switch.FPMA*
Management number of the FCoE switch.VP Index*
Status of the virtual ports.VP Status*
• Link Down
• Link Up (Logged In)
• Link Up (Logged Out)
Model name and serial number of the virtual storage machine that has the port.Virtual Storage Machine*
Opens the Edit Ports window.Edit Ports
370 LUN Manager GUI reference
