Rear panel components
Item Icon Component Item Icon Component
(1) Power button
On: The computer is on.
Blinking white: The hard drive is being
accessed.
(8) PS/2 keyboard jack
(2) Security cable slot (9) PS/2 mouse jack
(3) Power connector (10) Audio-in (microphone) jack
(4) Serial port (11) Audio-out (headphone)
(5) USB 3.x SuperSpeed ports (6) (12) Ethernet ports (2; select products only)
(6) RJ-45 (network) jack (13) PCIe slots (7)
(7) RJ-45 (network) jack (AMT enabled)
Rear panel components 5
