Page #55 background imageLoading...
Page #55 background image
Table 5-3 Computer Setup—Advanced (for advanced users) (continued)
Option Heading
USB redirection allows USB devices plugged into a client computer to be transparently redirected to
the guest operating system.
Uncongure AMT on next boot (Do Not Apply/Apply). Default is ‘Do Not Apply’.
SOL Terminal Emulation Mode (ANSI / VT100). Default is ANSI.
SOL terminal emulation mode is only activated during remote AMT redirection operations. The emulation
options allow administrators to select which mode works best with their console.
Show Uncongure ME Conrmation Prompt (enable/disable). Default is enabled.
Verbose Boot Messages (enable/disable). Default is enabled.
Verbose boot shows additional logging information during the boot. mainly for debugging if something goes
wrong during bootup.
Watchdog Timer (enable/disable). Default is enabled.
Allows you to set amount of time for a operating system and BIOS watchdog alert to be sent if the timers are
not deactivated. BIOS watchdog is deactivated by BIOS and would indicate that a halt occurred during
execution if the alert is sent to the management console. An operating system alert is deactivated by
the operating system image and would indicate that a hang occurred during its initialization.
OS Watchdog Timer (min.) – (5/10/15/20/25). Default is 5 min.
BIOS Watchdog Timer (min.) – (5/10/15/20/25). Default is 5 min.
CIRA Timeout (min.) (1/2/3/4/Never)
CIRA is Customer Initiated Remote Assistance, an Intel service to help users employing Active Management
Technology (AMT).
Recovering the Conguration Settings
This method of recovery requires that you rst perform the Save to Removable Media command with
the Computer Setup (F10) Utility before Restore is needed. (See Computer Setup–Main on page 39 in
the Computer Setup—File table.)
The Save to Removable Media option creates a le named HPSETUP.TXT on an inserted USB ash media
device. This le can be edited to change the settings on Restore. An asterisk (*) marks the selected option for a
setting.
NOTE: It is recommended that you save any modied computer conguration settings to a USB ash media
device and save the device for possible future use.
To restore the conguration, insert the USB ash media device with the saved conguration and perform
the Restore from Removable Media command with the Computer Setup (F10) Utility. (See Computer Setup–Main
on page 39 in the Computer Setup—File table.)
Recovering the Conguration Settings 47
