Storage device
1. Prepare the computer for disassembly (see Preparation for disassembly on page 17).
2. Remove the access panel (see Access panel on page 22).
3. Release the drive cage door (1) by swinging it open.
4. Remove the drive cage (2) from the computer.
5. Separate the drive cage retention arms (1) from the storage device, making sure the retention pins (2) fully
release from the device.
6. Remove the storage device (3) from the drive cage.
Reverse this procedure to install the storage device.
Storage device 23
