HP Z8 G4 Maintenance And Service Guide

If it becomes necessary to call for technical assistance, be prepared to do the following to ensure that your
service call is handled properly:
●
Be in front of your computer when you call.
●
Write down the computer serial number, product ID number, and monitor serial number before calling.
●
Spend time troubleshooting the problem with the service technician.
●
Remove any hardware that was recently added to your system.
●
Remove any software that was recently installed.
●
Restore the system from the Recovery Disc Set that you created or restore the system to its original
factory condition in System Software Requirement Disks (SSRD).
CAUTION: Restoring the system will erase all data on the hard drive. Be sure to back up all data les before
running the restore process.
NOTE: For sales information and warranty upgrades (Care Packs), call your local authorized service provider or
dealer.
Helpful hints
If you encounter problems with the computer, monitor, or software, see the following list of general suggestions
before taking further action:
●
Check that the computer and monitor are plugged into a working electrical outlet.
●
Check that the computer is turned on and the white power light is on.
●
Check that the monitor is turned on and the monitor light is on.
●
Check the Power LED on the front of the computer to see if it is ashing red. The ashing lights are error
codes that will help you diagnose the problem. Refer to POST error messages and diagnostic front panel
LEDs and audible codes on page 73 for more information.
●
Turn up the brightness and contrast controls of the monitor if the monitor is dim.
●
Press and hold any key. If the system beeps, then the keyboard should be operating correctly.
●
Check all cable connections for loose connections or incorrect connections.
●
Wake the computer by pressing any key on the keyboard or pressing the power button. If the system
remains in suspend mode, shut down the computer by pressing and holding the power button for at least
four seconds then press the power button again to restart the computer. If the system will not shut down,
unplug the power cord, wait a few seconds, then plug it in again. The computer will restart if it is set to
power on automatically as soon as power is restored in Computer Setup. If it does not restart, press
the power button to start the computer.
●
Recongure the computer after installing a non-plug and play expansion board or other option. See Solving
hardware installation problems on page 65 for instructions.
●
Be sure that all the needed device drivers have been installed. For example, if you are using a printer, you
need a driver for that model printer.
●
Remove all bootable media (CD/DVD or USB device) from the system before turning it on.
Helpful hints 49

HP Z8 G4 Specifications

General

Display included	No
Keyboard included	Yes
Power supply	1125 W
Operating system architecture	64-bit
Audio chip	Realtek ALC221
Product type	Workstation
Market positioning	Business
Motherboard chipset	Intel C622
Chassis type	Tower
Product color	Black
Country of origin	China
Number of 3.5\" bays	4
Number of 5.25\" bays	2
PCI Express x8 slots	3
Headphone outputs	1
HDMI ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	8
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
HDD speed	7200 RPM
HDD interface	SATA
Storage media	HDD
Optical drive type	DVD Super Multi
Card reader integrated	-
Total storage capacity	1000 GB
Memory slots	24x DIMM
Internal memory	8 GB
Memory channels	Hepta-channel
Memory clock speed	2666 MHz
Internal memory type	DDR4-SDRAM
Maximum internal memory	- GB
Memory layout (slots x size)	1 x 8 GB
Tcase	77 °C
Stepping	U0
Processor cache	11 MB
Processor model	4108
System bus rate	- GT/s
Processor socket	LGA 3647 (Socket P)
Processor threads	16
Processor codename	Skylake
Processor frequency	1.8 GHz
Processor cache type	L3
Processor lithography	14 nm
Processor manufacturer	Intel
PCI Express slots version	3.0
Processor boost frequency	3 GHz
Thermal Design Power (TDP)	85 W
Maximum number of PCI Express lanes	48
Memory clock speeds supported by processor	2400 MHz
Maximum internal memory supported by processor	768 GB
Scalability	2S
Processor code	SR3GJ
Processor ARK ID	123544
Intel TSX-NI version	1.00
Processor package size	76.0 x 56.5 mm
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2

Weight and Dimensions

Depth	551.2 mm
Width	215.9 mm
Height	444.5 mm
Weight	22400 g
