HPE Aruba Networking CX 6200 Series User Manual

Label
Description
9 Identification tab
10 RJ-45 console port
11 USB Type-C serial console port
Switch LEDs Function State Meaning
Back LED Status of modular components
installed in the back of the
chassis (not applicable for
6200F switches
On - Green Normal
Slow Flash - Amber Fault in one of the modules in
the back of the chassis
PoE LED Indicates Port LEDs are
showing PoE information (not
applicable for non PoE
switches)
Off PoE mode not selected
On - Green PoE mode selected
Slow Flash - Amber One or more ports
experiencing PoE failure. PoE
mode not selected.
On - Amber One or more ports
experiencing PoE failure. PoE
mode selected.
Spd LED Indicates Port LEDs are
showing speed information
Off Speed mode not selected
On - Green Speed mode selected
Not Implemented No fault defined
Stk LED Indicates Port LEDs are
showing stacking mode
information
Off Stacking mode not selected
On - Green Stacking mode selected
On - Amber One of the switch is
experiencing stacking failure.
Port LEDs will be used to
indicate the number of the
stacking member.
Slow flash Amber A port has a stacking failure.
Stacking mode not selected
UID LED Locator LED Off User configured the located
LED : OFF
On/Flash Blue (for
30 min)
User configured the locator
LED: On/Flash
Global Status
Indicator LED
Overall status of the product Flash - Green Self-test in progress during
UBOOT and SVOS
On - Green Successfully booted AOS-CX
Table 17: Front Panel LED Behavior
HPE Aruba Networking CX 6200F/M Switch Series Installation and Getting Started Guide |
21
