HPE Aruba Networking CX 6200 Series

Introducing the switches | 20
Label
Description
2 System Status LEDs
3 4p 10G SFP ports
4 LED mode select button
5 USB Type-C serial console port
6 USB Type-A Auxiliary port
7 Identification tab
8 RJ-45 console port
9 10/100/1000 Mbps Out-of-Band Management port
Figure 11 Switch and port LEDs for 6200F switches:HPEAruba Networking CX 6200F 12G Class4 PoE
2G/2SFP+ 139W switch (R8Q72A) and HPEAruba Networking CX 6200F 12G Class4 PoE 2G/2SFP+ 139W TAA
Switch (R8V13A)
Label
Description
1 12p 1G Base-T Class4 PoE ports
2 2p 1G Base-T ports
3 2p 10G SFP ports
4 Reset LED button
5 LED mode select button
6 System status LEDs
7 10/100/1000 Mbps Out-of-Band Management port
8 USB Type-A Auxilary port
Table 16: Switch and Port LEDs: Labels and Description
