Name Value
Status The Status of the element, useful for troubleshooting to identify
elements that are down or degraded.
Rolled Up Status The worst status of the components in the hierarchy below this item.
If there is a fault, drill down into the lower elements in the hierarchy
to get further information. If alerting and SNMP have been enabled,
messages will be sent to you automatically identifying the source of
the problem.
Diagnostic Messages Contains any diagnostic messages.
Additional Properties Varies according to the hardware element.
Monitoring the StoreOnce System server
The server hardware structure in the Navigator is not identical for all models.
There is a server entry for each node in the StoreOnce System. For example, a single couplet system has
two server entries; a four couplet system has eight server entries. The node name is included in the
server field to aid identification. There is also a Failback This Server button at the top of the node page
that allows you to bring a failed node back into a cluster, once the problem that caused the node to fail
has been resolved.
The following installed hardware components are included under the tree hierarchy for the server. If the
Status or Rolled Up Status is Down or Degraded, look at the Diagnostic Messages for more details.
Name Description
CPU Central processing unit
Fans Appliance fans
HBA (PCI-E Slot x) This is the Fibre Channel card and PCI-E slot number where it is installed.
Expand to see Ports information for this Fibre Channel card.
NOTE: There is a separate entry for each installed Fibre Channel card.
iLO Modules Integrated Lights-Out embedded server management
Memory DIMMs Dual In-line memory module
NIC 1 These are the 1GbE ports. Expand Ports to map physical ports to eth0, eth1,
eth2 and eth3.
NIC N (PCI-E Slot x) This is the 10GbE card and the location of the PCI-E slot number where it is
installed. Expand to see Ports information for this 10 GbE card.
NOTE: There is a separate entry for each installed 10 GbE card.
Table Continued
124 Monitoring the StoreOnce System server
