Table 18: Replication library parameters
Name The name of the library, defined when the library device was created.
Replication Role The role, which may be Non Replicating, Replication-Source, or
Replication-Target. All library devices are initially Non Replicating
until slots have been configured using this page.
Status The status of the local library (such as online).
User Data Stored The amount of user data stored.
Size On Disk The amount of space used on the disk.
Mapped/Total Slots The number of slots that have been mapped out of the total number
of slots configured on the library device.
Device Type The emulation type configured for that library.
Longest Time Out Of Sync The longest time out of sync.
Library Version The version number of the library.
Replication status Replication status, which may be Synchronised, Synchronising, or
Pending Synchronisation.
Service Set The Service Set on which the library is configured.
Slot mappings
Select a local library to display slot mappings for that library.
Users with an administrator login may also remove a slot mapping by clicking the Remove button.
Table 19: Slot mapping parameters
Replication-Source or Replication-Target library selected
Slot Mapping Name The slot mapping name. It is created when you run the
wizard to define the grouping of slots that you select.
Source/Target Appliance Name The name of the Target Appliance to which cartridges will
be replicated.
Source/Target Appliance Address The virtual IP address of the service set.
Source/Target Appliance Online Indicates whether a replication link is established with the
partner appliance.
Source/Target Appliance Serial Number The serial number of the Target Appliance to which
cartridges will be replicated.
Table Continued
Replication functions 65
