HPE XP7

• Usage: % full of the journal group
• Qmarker: Current data address being transferred, indicates the latest seq# for writing to the P-Vols
CTGroup at the PAIR state.
• Qcnt: Pending writes, shows the remaining total Qmarker within the journal data.
If there are no associated continuous access journal groups configured, – is displayed in the Jrnl Grp
column.
View ThP Pool Occupancy information
The ThP volumes that belong to a ThP Pool are displayed as THP-PID(<poolid>)and snapshot
volumes that belong to a snapshot pool are represented as Snap-PID(<pool id>), under RAIDGroup
in the LDEV table. Click a THP-PID(<poolid>) to view the ThP pool occupancy information, which
includes the mapping between the pool volumes (real LDEVs) and the V-VOLs.
Screen elements Description
THP Pool ID The ID of the pool (pool number)
THP Pool Status The status of the ThP Pool
• 0: Undefined/Creating/Deleting – Specified pool does not exist
completely.
• 1: Normal
• 2: Pool capacity beyond threshold
• 3: Pool capacity reached 100% of the pool
• 4: Failure, cannot show further information for the pool
POOL Threshold 1 A user configurable pool threshold (varying between 5% - 95% in
increments of 5%). The default value is 70%. This is the high for
the pool.
POOL Threshold 2 The threshold level that indicates the WARNING level for the pool.
This value is always 80% and cannot be changed.
THP Pool capacity The total capacity of all the ThP volumes in the pool.
THP Pool unused capacity The available capacity for the ThP pool.
VVOL ID The CU:LDEV identifier for the virtual volume (V-VOL).
VVOL Threshold (%) The threshold set for the V-VOL in ThP pool.
VVOL Capacity (MB) The capacity of the virtual volume (in MB).
REAL LDEV The physical LDEV that is part of the pool.
Table Continued
226 View ThP Pool Occupancy information
