Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual 117
Code Name Range Default Unit Attributes Setting
F07.01
Asynchronous motor
rated voltage
0Vcontroller rated voltage
model
1V ×
F07.02
Asynchronous motor
rated current
0.0999.9A 0.1A ×
F07.03
Asynchronous motor
rated frequency
1.00100.00Hz 50.00Hz 0.01Hz ×
F07.04
Asynchronous motor
rated rpm
124000rpm 1440rpm 1rpm ×
F07.05
Asynchronous motor
rated power factor
0.0011.000
Depend on
controller
model
0.001 ×
F07.06
Asynchronous motor
parameter auto-tuning
0: No action
1: Motor static auto-tuning
2: Motor rotation auto-tuning
0 1 ×
F07.07
Asynchronous motor
stator resistance
0.0009.999Ω
Depend on
controller
model
0.001Ω ×
F07.08
Asynchronous motor
rotor resistance
0.0009.999Ω 0.001Ω ×
F07.09
Asynchronous motor
leakage inductance
0.099.9mH 0.1mH ×
F07.10
Asynchronous motor
mutual inductance
0.0999.9mH 0.1mH ×
F07.11
Asynchronous motor
excitation current
0.0999.9A 0.1A ×
F07.12
Asynchronous motor of
core saturation
coefficient 1
0.000.50 (Magnetic flux is
set as 50%)
0.50 0.01 ×
F07.13
Asynchronous motor of
core saturation
coefficient 2
0.000.75 (Magnetic flux is
set as 75%)
0.75 0.01 ×
F07.14
Asynchronous motor of
core saturation
coefficient 3
0.001.20 (Magnetic flux is
set as 120%)
1.20 0.01 ×
F07.15
Asynchronous motor
torque boost
0.130.0% 0.1% 0.1%
F07.16
Asynchronous motor
torque boost end-point
0.050.0%(F07.03) 2.0% 0.1%
F07.17
Asynchronous motor of
slip compensation gain
0.0300.0% 100.0% 0.1%
F07.18
Asynchronous motor of
slip compensation filter
time
0.110.0s 0.1s 0.1s
F07.19
Asynchronous motor of
slip compensation
limitation
0.0250.0% 200.0% 0.1% ×
F07.20 AVR function
0: No action
1: Action all the time
1 1
