Page #131 background imageLoading...
Page #131 background image
Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
122 HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
F13.08 AI2 gain -10.0010.00 1.00 0.01
F13.09 AI2 filter time 0.0110.00s 0.05s 0.01s
F13.10 AI3 bias -100.0100.0% 0.0% 0.1%
F13.11 AI3 gain -10.0010.00 1.00 0.01
F13.12 AI3 filter time 0.0110.00s 0.05s 0.01s
F13.13 AI4 bias -100.0100.0% 0.0% 0.1%
F13.14 AI4 gain -10.0010.00 1.00 0.01
F13.15 AI4 filter time 0.0110.00s 0.05s 0.01s
F13.16
AO1 terminal output
function
0: Disable
1: Running speed (0max
output speed)
2: Setting speed (0max
output speed)
3: Output current (0twice of
controller rated current)
4: Output voltage (01.2
times of controller rated
voltage)
5: DC bus voltage (02.2
times of controller rated
voltage)
6: AI1 input (010V)
79: AI2AI4 input (-10
10V/020mA)
0 1
F13.17
AO2 terminal output
function
0 1
F13.18 AO1 bias -100.0100.0% 0.0% 0.1%
F13.19 AO1 gain 0.0200.0% 100.0% 0.1%
F13.20 AO2 bias -100.0100.0% 0.0% 0.1%
F13.21 AO2 gain 0.0200.0% 100.0% 0.1%
Group F14 SCI Communication Parameters (on pages 79
79)
F14.00 Data format
0: 1-8-2 format, no parity,
RTU
1: 1-8-1 format, even parity,
RTU
2: 1-8-1 format, odd parity,
RTU
3: 1-7-2 format, no parity,
ASCII
4: 1-7-1 format, even parity,
ASCII
5: 1-7-1 format, odd parity,
ASCII
0 1 ×
F14.01 Baud rate selection
0: 1200bps
1: 2400bps
2: 4800bps
3: 9600bps
4: 19200bps
3 1 ×
