Code Name Range Default Unit Attributes Setting
5: 38400bps
F14.02 Local address 0－247 2 1 ×
F14.03 Host PC response time 0－1000ms 0ms 1ms ×
F14.04
Detection time of
communication timeout
0.0－1000.0s
0.0: No detect at timeout
0.0s 0.1s ×
F14.05
Detection time of
communication error
0.0－1000.0s
0.0: No detect at error
0.0s 0.1s ×
F14.06－F14.47 Reserved
Group F15 Display Control Parameters (on pages 79
－
81)
F15.00 Language select
0: Chinese
1: English
2－9: Reserved
0 1 ○
F15.01
LCD panel display
contrast
1－10 5 1 ○
F15.02
Run display parameter 1
set
0: Disable
1: Controller rated current
2: Controller state
3: Operate channel
4: Setting speed
5: Setting speed (after
acc/dec)
6: Output frequency
7: Setting Rpm
8: Actual Rpm
9: Reserved
10: Output voltage
11: Output current
12: Output torque
13: Output power
14: DC bus voltage
15: AI1 voltage
16: AI1 voltage(After
disposal)
17: AI2 voltage
18: AI2 voltage(After
disposal)
19: AI3 voltage
20: AI3 voltage(After
disposal)
21: AI4 voltage
22: AI4 voltage(After
disposal)
23: AO1 output
24: AO2 output
25: Heatsink temperature
26: Input terminal state
5 1 ○
F15.03
Run display parameter 2
set
6 1 ○
F15.04
Run display parameter 3
set
10 1 ○
F15.05
Run display parameter 4
set
11 1 ○
F15.06
Run display parameter 5
set
0 1 ○
F15.07
Run display parameter 6
set
0 1 ○
F15.08
Stop display parameter
1 set
4 1 ○
F15.09
Stop display parameter
2 set
14 1 ○
F15.10
Stop display parameter
3 set
16 1 ○
F15.11
Stop display parameter
4 set
26 1 ○
F15.12
Stop display parameter
5 set
27 1 ○
F15.13
Stop display parameter
6 set
0 1 ○
