Shenzhen Hpmont Technology Co., Ltd Appendix A Parameters
HD5L Series Controller User Manual －125－
Code Name Range Default Unit Attributes Setting
F17.05
The detect base of lack
of output
0－100%(controller rated
current)
20% 1% ×
F17.06
The detect time of lack
of output
0.0－20.0s 3.0s 1.0s ×
F17.07
Motor overload protect
factor
20.0－110.0% 100.0% 1.0% ×
F17.08 Fault auto restet times
0－100
0: No auto reset function
0 1 ×
F17.09 Fault auto reset interval 2.0－20.0s/time 5.0s/time
0.1
s/time
×
F17.10 Fault relay action select
Units: during auto reset
0: Fault relay don’t act
1: Fault relay act
Tens: during DC bus low
0: Fault relay don’t act
1: Fault relay act
00 1 ○
F17.11 NO.5 fault type
Lu: DC bus low
E0001: Acc overcurrent
E0002: Dec overcurrent
E0003: Constant speed
overcurrent
E0004: Acc overvoltage
E0005: Dec overvoltage
E0006: Constant speed
overvoltage
E0008: Power module faulty
E0009: Heatsink overheated
E0010: Brake unit faulty
E0011: CPU faulty
E0012: Motor auto-tuning
faulty
E0013: Soft start failed
E0014: Current detect faulty
E0015: Lack of input
E0016: Lack of output
E0017: Controller overloaded
E0018: Excessive speed
deviation
E0019: Motor overloaded
E0020: Motr overheated
E0021: Controlborad
EEPROM faulty
E0022: Panel EEPROM
faulty
E0023: Parameter setting
faulty
0 1 *
