Appendix A Parameters Shenzhen Hpmont Technology Co., Ltd
―126― HD5L Series Controller User Manual
Code Name Range Default Unit Attributes Setting
E0024: External faulty
E0028: SCI timeout faulty
E0029: SCI faulty
E0030: PG direct wrong
E0031: PG disconnection
E0032: Motor over speed
E0033: Loss of Z signal of
ABZ Encoder
E0034: UVW signal wrong of
UVW Encoder
E0035: CD phase wrong of
SINCOS encoder
E0036: Contactor faulty
E0008、E0010、E0013、
E0014、E0021、E0022、
E0024、E0036 can’t auto
reset
F17.12
Setting freqency at NO.5
fault
0.00－100.00Hz 0.00Hz 0.01Hz *
F17.13
Output freqency at NO.5
fault
0.00－100.00Hz 0.00Hz 0.01Hz *
F17.14
DC bus vlotage at NO.5
fault
0－999V 0V 1V *
F17.15
Output voltage at NO.5
fault
0－999V 0V 1V *
F17.16
Output current at NO.5
fault
0.0－999.9A 0.0A 0.1A *
F17.17
Input terminal state at
NO.5 Fault
0－0x1FF 0 1 *
F17.18
Output terminal state at
NO.5 fault
0－0x3F 0 1 *
F17.19 NO.5 fault interval 0.0－6553.5 hour 0.0h 0.1h *
F17.20 NO.4 fault type 0－36 0 1 *
F17.21 NO.4 fault interval 0.0－6553.5 hour 0.0h 0.1h *
F17.22 NO.3 fault type 0－36 0 1 *
F17.23 NO.3 fault interval 0.0－6553.5 hour 0.0h 0.1h *
F17.24 NO.2 fault type 0－36 0 1 *
F17.25 NO.2 fault interval 0.0－6553.5 hour 0.0h 0.1h *
F17.26 NO.1 fault type 0－36 0 1 *
F17.27 NO.1 fault interval 0.0－6553.5 hour 0.0h 0.1h *
Group F18 PWM Parameters (on pages 85
－
85)
F18.00 Carrier fregency 1－16kHz
Depend on
controller
model
1kHz ×
F18.01
Carrier freqency auto
0: Disable 0 1 ×
