Shenzhen Hpmont Technology Co., Ltd Chapter 4 Electrical Installation
HD5L Series Controller User Manual ―35―
Encoder card connection
The connection of UVW encoder is shown as Figure 4-29.
Figure 4-29 Connection of UVW encoder
A
GND
PG
A+
A-
+5V
GND
OUTA OUTB
PGA PGB
PGVCC
B
B+
B-
Z
Z+
Z-
U
U+
U-
V
V+
V-
W
W+
W-
COM
COM
PE
PE
UVW encoder
Elevator controller
Interface circuit
the same as A
Interface circuit
the same as A
Interface circuit
the same as A
Interface circuit
the same as A
Interface circuit
the same as A
HD-PG6-UVW-FD
PG interface card
