HPRT TP809 Programming Manual

TP809 Programming Manual
7
<Function 69> GS ( L pL pH m fn kc1 kc2 x y (fn = 69)
[Function]
Print the specified NV graphics data
[Format]
ASCII
GS ( L pL pH m fn kc1 kc2 x y
Hex
1D 28 4C pL pH m fn kc1 kc2 x y
Decimal
29 40 76 pL pH m fn kc1 kc2 x y
[Range]
(pL + pH × 256) = 6 (pL = 6, pH = 0)
m = 48
fn = 69
32 ≤ kc1 ≤ 126
32 ≤ kc2 ≤ 126
x = 1, 2
y = 1, 2
[Description]
• Prints the NV graphics data defined by the key codes (kc1 and kc2).
• The graphics data is enlarged by x and y in the horizontal and vertical directions.
x, y
Vertical direction
Horizontal direction
1
203 dpi
203 dpi
2
101 dpi
101 dpi
