HPRT TP809 Programming Manual

TP809 Programming Manual
35
m
Bar code system
Range of n
Range of d
65
UPC-A
n = 11, 12
48 ≤ d ≤ 57
66
UPC-E
n = 11, 12
48 ≤ d ≤ 57 [where d1 = 48]
67
JAN13 / EAN13
n = 12, 13
48 ≤ d ≤ 57
68
JAN8 / EAN8
n = 7, 8
48 ≤ d ≤ 57
69
CODE39
1 ≤ n ≤ 255
48 ≤ d ≤ 57, 65 ≤ d ≤ 90,
d = 32, 36, 37, 42, 43, 45, 46,
47
70
ITF
2 ≤ n ≤ 254
(even number)
48 ≤ d ≤ 57
71
CODABAR ( NW-7)
2 ≤ n ≤ 255
48 ≤ d ≤ 57, 65 ≤ d ≤ 68,
97 ≤ d ≤ 100,
d = 36, 43, 45, 46, 47, 58
[where 65≤d1≤68, 65≤dn≤ 68,
97 ≤d1≤100, 97 ≤ dn ≤ 100]
72
CODE93
1 ≤ n ≤ 255
0 ≤ d ≤ 127
73
CODE128
2 ≤ n ≤ 255
0 ≤ d ≤ 127
[where d1 = 123, 65 ≤ d2 ≤ 67]
GS w n
[Function]
Set bar code width
[Format]
ASCII
GS w n
Hex
1D 77 n
Decimal
29 119 n
[Range]
2 ≤ n ≤ 6
[Range]
n = 3
[Description]
• Sets the horizontal size of the bar code.
• Multi-level bar codes are as follows: UPC-A, UPC-E, JAN13 / EAN13, JAN8 / EAN8,
CODE93, and CODE128
• Binary-level bar codes are as follows: CODE39, ITF, and CODABAR
n
Multi-level bar code
Binary-level bar code
Module width (mm)
Thin element width (mm)
Thick element width (mm)
2
0.25
0.25
0.625
3
0.375
0.375
2.303
4
0.5
0.5
1.250
5
0.625
0.625
1.625
6
0.750
0.750
2
