TP809 Programming Manual
40
<Function 081> GS ( k pL pH cn fn m (cn = 48, fn = 81)
[Function]
PDF417: Print the symbol data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m
Hex
1D 28 6B 03 00 30 51 m
Decimal
29 40 107 3 0 48 81 m
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 81
m = 48
[Description]
Encodes and prints the PDF417 symbol data in the symbol storage area with GS ( k
<Function 080>.
[Note]
• User must secure the quiet zone (left, right, upward, and downward space areas
defined by the PDF417 symbol specifications) for PDF417 printing.
• In standard mode, symbols higher than 831 dots cannot be printed with this printer.
<Function 082> GS ( k pL pH cn fn m (cn = 48, fn = 82)
[Function]
PDF417: Transmit the size information of the symbol data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m
Hex
1D 28 6B 03 00 30 52 m
Decimal
29 40 107 3 0 48 82 m
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 82
m = 48
[Description]
Transmit the size information for the encoded PDF417 symbol data in the symbol storage
area with GS ( k <Function 080>.
[Note]
• This function does not print.
• The size information does not include the quiet zone (left, right, upward, and
downward space areas defined by the PDF417 symbol specifications).
