HPRT TP809 Programming Manual

TP809 Programming Manual
42
<Function 180> GS ( k pL pH cn fn m d1…dk (cn = 49, fn = 80)
[Function]
QR Code: Store the data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m d1…dk
Hex
1D 28 6B pL pH 31 50 30 d1…dk
Decimal
29 40 107 pL pH 49 80 48 d1…dk
[Range]
4 ≤ (pL + pH × 256) ≤ 7092 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 27)
cn = 49
fn = 80
m = 48
0 ≤ d ≤ 255
k = (pL + pH × 256) – 3
[Description]
Store the QR Code symbol data (d1...dk) into the symbol storage area
<Function 181> GS ( k pL pH cn fn m (cn = 49, fn = 81)
[Function]
QR Code: Print the symbol data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m
Hex
1D 28 6B 03 00 31 51 m
Decimal
29 40 107 pL pH cn fn m
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 49
fn = 81
m = 48
[Description]
Encodes and prints the QR Code symbol data in the symbol storage area with GS ( k
<Function 180>.
[Note]
User must secure the quiet zone (left, right, upward, and downward space areas defined
by the QR Code symbol specifications) for QR Code printing.
