HPRT TP809 Programming Manual

TP809 Programming Manual
38
<Function 068> GS ( k pL pH cn fn n (cn = 48, fn = 68)
[Function]
PDF417: Set the row height
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 44 n
Decimal
29 40 107 3 0 48 68 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 68
2 ≤ n ≤ 8
[Default]
n = 3
[Description]
Set the row height for PDF417 to [n × (the width of the module)]
• When m = 49, the error correction level is set by the “Ratio Setting” to the level
indicated by the number for encoded data, and the error correction level set by the
“Level Setting” is canceled. The rate is set to [n× 10%].
The error correction levels in the following table are determined by the calculation
[Data codeword × n × 0.1 = (A)] (Fractions of 0.5 and over are rounded up, and
others are truncated.)
<Function 069> GS ( k pL pH cn fn n (cn = 48, fn = 69)
[Function]
PDF417: Set the error correction level
[Format]
ASCII
GS ( k pL pH cn fn m n
Hex
1D 28 6B 04 00 30 45 m n
Decimal
29 40 107 4 0 48 69 m n
[Range]
(pL + pH × 256) = 4 (pL = 4, pH = 0)
cn = 48
fn = 69
m = 48, 49
48 ≤ n ≤ 56 [when m = 48]
1 ≤ n ≤ 40 [when m = 49]
[Default]
m = 49, n= 1
[Description]
•Sets the error correction level for PDF417.
•When m = 48, the error correction level is se t by the “Level Setting” and the error
correction level set by “Ratio Setting” is canceled. The number of error correction
codewords are as follows:
