HPRT TP809

TP809 Programming Manual
13
GS W nL nH
[Function]
Set print area width
[Format]
ASCII
GS W nL nH
Hex
1D 57 nL nH
Decimal
29 87 nL nH
[Range]
0 ≤ (nL + nH × 256) ≤ 65535 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255)
[Default]
(nL + nH × 256) = 576 (nL = 40, nH = 2) [80 mm paper width model]
(nL + nH × 256) = 406 (nL = 80, nH = 1) [58 mm paper width model]
[Description]
In standard mode, sets the print area width to [(nL + nH × 256) × (horizontal motion
unit)].
GS \ nL nH
[Function]
Set relative vertical print position in page mode
[Format]
ASCII
GS \ nL nH
Hex
1D 5C nL nH
Decimal
29 92 nL nH
[Range]
-32768 ≤ (nL + nH × 256) ≤ 32767
[Description]
• In page mode, moves the vertical print position to [(nL + nH × 256) × (vertical or
horizontal motion unit)] from the current position.
• A positive number specifies downward movement, and a negative number specifies
upward movement.
