HPRT TP809 Programming Manual

TP809 Programming Manual
39
n
Function
number of error correction codewords
48
Select error correction level0
2
49
Select error correction level1
4
50
Select error correction level2
8
51
Select error correction level3
16
52
Select error correction level4
32
53
Select error correction level5
64
54
Select error correction level6
128
55
Select error correction level7
256
56
Select error correction level8
512
Result(A)
Use the error correction level
number of error correction codewords
0~3
Error correction level1
4
4~10
Error correction level2
8
11~20
Error correction level3
16
21~45
Error correction level4
32
46~100
Error correction level5
64
101~200
Error correction level6
128
201~400
Error correction level7
256
401 or more
Error correction level8
512
<Function 080> GS ( k pL pH cn fn m d1…dk (cn = 48, fn = 80)
[Function]
PDF417: Store the data in the symbol storage area
[Format]
ASCII
GS ( k pL pH cn fn m d1…dk
Hex
1D 28 6B pL pH 30 50 30 d1…dk
Decimal
29 40 107 pL pH 48 80 48 d1…dk
[Range]
4 ≤ (pL + pH × 256) ≤ 65535 (0 ≤ pL ≤ 255, 0 ≤ pH ≤ 255)
cn = 48
fn = 80
m = 48
0 ≤ d ≤ 255
k = (pL + pH × 256) – 3
[Description]
Stores the PDF417 symbol data (d1...dk) in the symbol storage area
