TP809 Programming Manual

ESC W xL xH yL yH dxL dxH dyL dyH

[Function]

Set print area in page mode

[Format]

ASCII

ESC W xL xH yL yH dxL dxH dyL dyH

Hex

1B 57 xL xH yL yH dxL dxH dyL dyH

Decimal

27 87 xL xH yL yH dxL dxH dyL dyH

[Range]

0 ≤ (xL + xH × 256) ≤ 65535; (0 ≤ xL ≤ 255, 0 ≤ xH ≤ 255)

0 ≤ (yL + yH × 256) ≤ 65535; (0 ≤ yL ≤ 255, 0 ≤ yH ≤ 255)

1 ≤ (dxL + dxH × 256) ≤ 65535; (0 ≤ dxL ≤ 255, 0 ≤ dxH ≤ 255)

1 ≤ (dyL + dyH × 256) ≤ 65535; (0 ≤ dyL ≤ 255, 0 ≤ dyH ≤ 255)

[Default]

(xL + xH × 256) = 0 (xL = 0, xH = 0)

(yL + yH × 256) = 0 (yL = 0, yH = 0)

(dxL + dxH × 256) = 576 (dxL = 0, dxH = 2)

[80 mm paper width model]

(dxL + dxH × 256) = 384 (dxL = 104, dxH = 4)

[58 mm paper width model]

(dyL + dyH × 256) = 1662 (dyL = 126, dyH = 6)

[Description]

• In page mode, sets the size and the logical origin of the print area.

• xL, xH specify the horizontal logical origin as [(xL + xH × 256) × (horizontal motion unit)]

from absolute origin.

• yL, yH specify the vertical logical origin as [(yL + yH × 256) × (vertical motion unit)] from

absolute origin.

• dxL, dxH specify the horizontal dimension of print area as [(dxL + dxH × 256) ×

(horizontal motion unit)].

• dyL, dyH specify the vertical dimension of print area as [(dyL + dyH × 256) × (vertical

motion unit)].

[Note]

When single-color print control is selected, the vertical dimension of the print area can

be set to 207.95 mm {3324/360"} maximum.
