HPRT TP809

TP809 Programming Manual
37
<Function 067> GS ( k pL pH cn fn n (cn = 48, fn = 67)
[Function]
PDF417: Set the width of the module
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 43 n
Decimal
29 40 107 3 0 48 67 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 67
2 ≤ n ≤ 8
[Default]
n = 3
[Description]
Sets the width of the module for PDF417 to n dots
<Function 065> GS ( k pL pH cn fn n (cn = 48, fn = 65)
[Function]
PDF417: Set the number of columns in the data region
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 41 n
Decimal
29 40 107 3 0 48 65 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 65
0 ≤ n ≤ 30
[Default]
n =0
[Description]
Sets the number of columns in the data region for PDF417.
<Function 066> GS ( k pL pH cn fn n (cn = 48, fn = 66)
[Function]
PDF417: Set the number of rows
[Format]
ASCII
GS ( k pL pH cn fn n
Hex
1D 28 6B 03 00 30 42 n
Decimal
29 40 107 3 0 48 66 n
[Range]
(pL + pH × 256) = 3 (pL = 3, pH = 0)
cn = 48
fn = 66
n=0, 3 ≤ n ≤ 90
[Default]
n = 0
[Description]
Sets the number of rows for PDF417.
