HPRT TP809 Programming Manual

TP809 Programming Manual
12
ESC a n
[Function]
Select justification
[Format]
ASCII
ESC a n
Hex
1B 61 n
Decimal
27 97 n
[Range]
0 ≤ n ≤ 2, 48 ≤ n ≤ 50
[Default]
n = 0
[Description]
In standard mode, aligns all the data in one line to the selected layout.
n
Justification
0,48
Left justification
1, 49
Centering
2, 50
Right justification
ESC D n1...nk NUL
[Function]
Setting horizontal tab position
[Format]
ASCII
ESC D n1 ...nk NUL
Hex
1B 44 n1 ...nk 00
Decimal
27 68 n1 ...nk 0
[Range]
1 ≤ n1 ≤ n2 ≤ ... ≤ nk ≤ 255
0 ≤ k ≤ 32
[Default]
n = 8, 16, 24, 32, 40, ..., 232, 240, 248
[for Font A (12 × 24) in a standard character size width]
[Description]
• Sets horizontal tab positions.
• n specifies the number of digits from the setting position to the left edge of the print
area.
• k is used to indicate the number of bytes set for the horizontal tab position.
GS L nL nH
[Function]
Set left margin
[Format]
ASCII
GS L nL nH
Hex
1D 4C nL nH
Decimal
29 76 nL nH
[Range]
0 ≤ (nL + nH × 256) ≤ 65535 (0 ≤ nL ≤ 255, 0 ≤ nH ≤ 255)
[Default]
(nL + nH × 256) = 0 (nL = 0, nH = 0)
[Description]
In standard mode, sets the left margin to [(nL + nH × 256) × (horizontal motion unit)].
