TP809 Programming Manual
36
GS ( k pL pH cn fn [parameters]
[Function]
Set up and print symbol
[Description]
• Processes the data for symbols.
• pL, pH specify (pL + pH × 256) as the number of bytes after pH (cn, fn, and
[parameters]).
• cn specifies the type of symbol.
• fn specifies the function.
• [parameters] specify the process of each function.
[Note]
• "Symbol data" means the data received with <Function 080 or 180> before encoding.
• "Symbol storage area" means the area where the data received with <Function 080 or
180> before encoding is stored.
• When <Function 082 or 182> is transmitted, do not transmit the subsequent data until
the status is received.
• PDF417 (cn=48) is supported in ANK model.
cn
Type of Symbol
48
PDF417 (two-dimensional codes)
49
QR Code (two-dimensional codes)
cn
fn
Format
Function
No.
Function name
48
65
GS ( k pL pH cn fn n
065
PDF417: Set the number of columns in the data region.
66
GS ( k pL pH cn fn n
066
PDF417: Set the number of rows.
67
GS ( k pL pH cn fn n
067
PDF417: Set the width of the module.
68
GS ( k pL pH cn fn n
068
PDF417: Set the row height.
69
GS ( k pL pH cn fn m n
069
PDF417: Set the error correction level.
80
GS ( k pL pH cn fn m
d1...dk
080
PDF417: Store the data in the symbol storage area.
81
GS ( k pL pH cn fn m
081
PDF417: Print the symbol data in the symbol storage area.
82
GS ( k pL pH cn fn m
082
PDF417: Transmit the size information of the symbol data in
the symbol storage area.
67
GS ( k pL pH cn fn n
167
QR Code: Set the size of module.
49
69
GS ( k pL pH cn fn n
169
QR Code: Select the error correction level.
80
GS ( k pL pH cn fn m
d1...dk
180
QR Code: Store the data into the symbol storage area.
81
GS ( k pL pH cn fn m
181
QR Code: Print the symbol data in the symbol storage area.
82
GS ( k pL pH cn fn m
182
QR Code: Transmit the size information of the symbol data
in the symbol storage area.
