HPRT TP809 Programming Manual

TP809 Programming Manual
3
GS ( L pL pH m fn [parameters]
[Format]
ASCII
GS ( L pL pH m fn [parameters]
Hex
1D 28 4C pL pH m fn [parameters]
Decimal
29 40 76 pL pH m fn [parameters]
[Note]
• Frequent write command executions by an NV memory write command may damage
the NV memory.
Therefore, it is recommended to limit writing the commands into the NV memory to less
than 10 times a day.
• If the power is turned off or the printer is reset via an interface while this command is
being executed, the printer may go into an abnormal condition. Be careful not to turn
the power off or let the printer be reset via an interface while this command is being
executed.
• While processing this command, the printer is BUSY while writing the data to the NV
memory and stops receiving data. Therefore, be sure not to transmit data, including the
real-time commands, while the printer is BUSY.
• When <Function 48, 51, or 64> is transmitted, do not transmit the subsequent data
until the status is received. ESC/POS Handshaking Protocol procedures are required
when using <Function 64>.
fn
Format
Function No.
Function name
0，48
GS ( L pL pH m fn
48
Transmit the NV graphics memory capacity
2，50
GS ( L pL pH m fn
50
Print the graphics data in the print buffer
3，51
GS ( L pL pH m fn
51
Transmit the remaining capacity of the
NV graphics memory
64
GS ( L pL pH m fn d1 d2
64
Transmit the key code list for defined
NV graphics
65
GS ( L pL pH m fn d1 d2 d3
65
Delete all NV graphics data
66
GS ( L pL pH m fn kc1 kc2
66
Delete the specified NV graphics data
67
GS ( L pL pH m fn a kc1 kc2 b xL
xH yL yH [c d1...dk]1... [c
d1...dk]b
67
Define the NV graphics data (raster
format)
69
GS ( L pL pH m fn kc1 kc2 x y
69
Print the specified NV graphics data
112
GS ( L pL pH m fn a bx by c xL
xH yL yH d1…dk
112
Store the graphics data in the print
buffer (raster format)
