HT 400 Series User Manual

400 Series
EN - 10
5. MAIN MENU
Pressing the MENU/ESC key in any allowable condition of the instrument displays the
following screen, in which the instrument may be set, the saved measures can be
displayed and the desired measuring function may be set.
MENU
AUTO : Ra, RCD, M 
LOW
 : continuity
M
 : insulation
RCD : RCD tripping
LOOP : impedance
Ra : earth res.
123 : phase sequen.
AUX : environment
LEAK : leakage curr.
PWR : analyzer
 SET : settings
MEM : memory
RS232: data transfer
5.1. AUTO ÷ PWR
By selecting one of the measurements listed between AUTO and PWR with the cursor,
compatibly with the characteristics reported in Table 1 and confirming selection with
ENTER, the desired measurement is accessed.
5.2. SET – INSTRUMENT SETTINGS
Move the cursor to SET by means of the arrow keys (,)
and confirm with ENTER. Subsequently, the displays shows
the screen which allows accessing the various instrument
settings.
The settings will remain valid also after switching off the
instrument.
SET
Language
Auto power off
Nominal V
Frequency
System

VAL
5.2.1. Language
Move the cursor to Language by means of the arrow keys
(,) and confirm with ENTER. Subsequently, the displays
shows the screen which allows setting the instrument
language.
Select the desired option by means of the arrow keys (,).
To store settings, press the ENTER key, to exit the changes
made, press the ESC key.
LNG
Italiano
English
Español
Deutsch
Français
Svenska
Norsk
Dansk

VAL

HT 400 Series Specifications

General

Type	Digital Multimeter
Diode Test	Yes
Auto Ranging	Yes
Data Hold	Yes
Operating Temperature	0°C to 40°C
DC Current Range	400μA to 10A
AC Current Range	400μA to 10A
Resistance Range	400Ω to 40MΩ
Continuity Test	Yes
Display	LCD, 4000 counts
Measurement Range	As per individual functions
