HT 400 Series User Manual

400 Series
EN - 20
4. Once calibration is comple-
ted, in case the detected
value is lower than 5, the
instrument gives a double
acoustic signal which signals
the positive result of the test
and displays a screen similar
to the one reported here to
the side
LOW
----
R+ R-
---- ----
---mA ---mA
CAL
4.00 0.21
Value of the calibrated
resistance
Func Lim CAL
5. In order to delete the compensation resistance value of the cables, it is necessary to
perform a cable calibration procedure with a resistance higher than 5 at test leads
(e.g. with open test leads).
6.2.2. Description of anomalous results
1. By using the AUTO, R+ or R-
mode, in case the detected
value is higher than the set
limit, the instrument gives a
long acoustic signal and
displays a screen similar to
the one reported here to the
side
LOW
5.92
R+ R-
5.92 5.91
210mA 210mA
R > LIM
AUTO
4.00 0.21
Func Lim CAL
2. By using the AUTO, R+ or R-
mode, in case the detected
value is higher than the full
scale, the instrument gives a
long acoustic signal and
displays a screen similar to
the one reported here to the
side
LOW
>99.9
R+ R-
>99.9 >99.9
---mA ---mA
I < 200mA
AUTO
4.00 0.21
Func Lim CAL
3. By using the AUTO, R+ or R-
mode, if the instrument
detects a resistance which
prevents a current of 200mA
to circulate, it gives a long
acoustic signal and displays
a screen similar to the one
reported here to the side
LOW
20.0
R+ R-
20.0 20.0
157mA 157mA
I < 200mA
AUTO
4.00 0.21
Func Lim CAL
4.
The results displayed can be saved by pressing the SAVE key twice or the
SAVE key and, subsequently, the ENTER key (§ 8.1)
