400 Series
EN - 64
11. SPECIFICATIONS
Accuracy indicated as: ±[%rdg + (num. dgt * resolution)] at 23°C, <80%RH. Refer to the
Table 1 for the correspondence between models and available functions
11.1. TECHNICAL FERATURES
Continuity test (LOW)
Range [] Resolution []
Accuracy
0.00 9.99
0.01
(2.0rdg + 2dgt)
10.0 99.9
0.1
Test current: >200mA DC up to 5 (include the resistance of the calibration) also with half-charged battery
Generated current: resolution 1mA, accuracy (5.0%rdg + 5dgt)
Open circuit test voltage: 4 < V
0
< 24V
Function mode: AUTO, R+, R-
Insulation resistance (M)
Test voltage [V]
Range [] Resolution []
Accuracy
50
0.01 9.99
0.01
(2.0rdg + 2dgt)
10.0 49.9
0.1
50.0 99.9
0.1
(5.0rdg + 2dgt)
100
0.01 9.99
0.01
(2.0rdg + 2dgt)
10.0 99.9
0.1
100 199
1
(5.0rdg + 2dgt)
250
0.01 9.99
0.01
(2.0rdg + 2dgt)
10.0 99.9
0.1
100 249
1
250 499
1
(5.0rdg + 2dgt)
500
0.01 9.99
0.01
(2.0rdg + 2dgt)
10.0 99.9
0.1
100 499
1
500 999
1
(5.0rdg + 2dgt)
1000
0.01 9.99
0.01
(2.0rdg + 2dgt)
10.0 99.9
0.1
100 999
1
1000 1999
1
(5.0rdg + 2dgt)
Open circuit test voltage: < 1.25 x nominal test voltage
Short circuit current: < 15mA (peak) with each test voltage
Generated voltage: resolution: 1V, Accuracy (5.0%rdg + 5dgt) @ Rmis> 0.5% FS
Nominal test current: > 2.2mA with 230k @ 500V ; >1mA with 1k @ other Vnom
Test on RCDs
Phase-neutral and phase-earth voltage range (110 240V) 10%
Frequency 50Hz 0.5Hz, 60Hz 0.5Hz
Nominal test current (IdN) 10mA,30mA,100mA,300mA,500mA,650mA,1A
Contact voltage (ULIM) 25V, 50V
Tripping time (x½, x1, x2, x5, AUTO)
Multiplier [x IdN] Range [ms] Resolution [ms] Accuracy
½, 1
1 999 general and selective
1
(2.0rdg + 2dgt)
2
1 200 general
1 250 selective
5
1 50 general
1 160 selective
RCD type: AC ( ), A ( ), general and selective
Nominal test current (IdN): multiplier x1, x2, x5, AUTO: accuracy: -0%, +10% IdN
multiplier x½: accuracy: -10%, +0% IdN
