400 Series
EN - 65
Tripping current ( )
IdN [mA] Type Range IdN [mA] Resolution [mA] Accuracy
≤ 10
AC
(0.5 1.1) IdN
0.1IdN -0%, +10%rdg
A
(0.3 1.1) IdN
> 10
AC
(0.5 1.1) IdN
A
(0.3 1.1) IdN
RCD type: AC ( ), A ( ), general and selective
Tripping time resolution 1ms, Accuracy (2.0%rdg + 2dgt)
Global earth resistance without RCD’s tripping (Ra)
Range [] Resolution []
Accuracy
1 1999
1
(5.0rdg + 3dgt)
RCD type: AC ( ), A ( ), general and selective
Test current < ½ IdN, accuracy: -10%, +0% IdN
Contact voltage Ut range: 0 2Ut lim, resolution: 0.1V, accuracy: -0%, +(5%rdg + 3dgt)
Line/Loop fault impedance
Phase-neutral and phase-earth voltage range (110 240V) 10%
Phase-phase voltage range (110 415V) 10%
Frequency 50Hz 0.5Hz, 60Hz 0.5Hz
TT and TN systems
Range [] Resolution []
Accuracy
0.01 19.99
0.01
(5.0rdg + 3dgt)
20.0 199.9
0.1
200 1999 (phase-earth only)
1
Max peak test current at test voltage 3A @ 127V, 6A @ 230V, 10A @ 400V
IT systems (first fault current)
Range [mA] Resolution [mA] Accuracy
5 999
1
(5.0rdg + 3dgt)
Contact voltage (ULIM) 25V, 50V
Global earth resistance (Ra)
Range [] Resolution []
Accuracy
0.01 19.99
0.01
(5.0rdg + 1)
20.0 199.9
0.1
200 1999 (phase-earth only)
1
Test current: <15mA
Contact voltage (ULIM): 25V, 50V
Phase-neutral and phase-earth: (110 240V) 10%
Frequency: 50Hz 0.5Hz, 60Hz 0.5Hz
Phas sequence (123)
Phase-neutral and phase-earth voltage range (110 240V) 10%
Frequency 50Hz 0.5Hz, 60Hz 0.5Hz
Leakage current (LEAK)
Range [mV] Resolution [mV] Accuracy
1 1200.0
0.1
(1.0rdg + 2dgt)
Max crest factor: 3
Response time: 10ms
Frequency: 50Hz 0.5Hz, 60Hz 0.5Hz
