HT 400 Series User Manual

400 Series
EN - 43
9. By using the P-PE mode, if
the instrument detects that,
in case the test should be
performed, a contact voltage
higher than the set limit
would build up in the system
being tested, it does not
perform the test and displays
the message reported here
to the side. Check the
LOOP
0°
----
---A
FRQ=50.0Hz
VP-N=231V VP-Pe=231V
Ut > Ulim
Dangerous contact voltage
P-PE STD
Func Mod.
efficiency of the protective conductor and the earthing
10. If, after repeated tests, the
instrument has overheated,
the message reported here
to the side is displayed. Wait
for this message to
disappear before performing
other tests
LOOP
----
---A
FRQ=50.0Hz
VP-N=231V VP-Pe=231V
Hot temperature
Overheated instrument
P-N STD
Func Mod.
11. The previous anomalous results cannot be saved

HT 400 Series Specifications

General

Type	Digital Multimeter
Diode Test	Yes
Auto Ranging	Yes
Data Hold	Yes
Operating Temperature	0°C to 40°C
DC Current Range	400μA to 10A
AC Current Range	400μA to 10A
Resistance Range	400Ω to 40MΩ
Continuity Test	Yes
Display	LCD, 4000 counts
Measurement Range	As per individual functions
