HT GSC60 User Manual

GSC60
EN - 106
Active power (@ 230V, I> 5% FS, cos>=0.5, f=50.0Hz)
FS clamp Range [kW] Resolution [kW] Accuracy
 10A
0.000  9.999
0.001
(2.0rdg + 7dgt)
10.00  99.99
0.01
10A < FS  200
0.00  99.99
0.01
100.0  999.9
0.1
200A < FS  1000
0.0  999.9
0.1
1000  9999
1
1000A < FS  3000 0  9999
1
Reactive power (@ 230V, I> 5% FS, cos<0.9, f=50.0Hz)
FS clamp Range [kVAr] Resolution [kVAr] Accuracy
 10A
0.000  9.999
0.001
(2.0rdg + 7dgt)
10.00  99.99
0.01
10A < FS  200
0.00  99.99
0.01
100.0  999.9
0.1
10A < FS  200
0.0  999.9
0.1
1000  9999
1
1000A < FS  3000 0  9999
1
Power factor / cos (@ 230V, I >5%FS)
Range Resolution Accuracy
0.70c  1.00  0.70i
0.01
(2.0rdg + 3rdg)
Voltage harmonics (@ 230V in 1Ph systems, 400V in 3Ph systems)
Range [%] Resolution [%] Ordine Accuracy
0.1  100.0
0.1
DC, 01  49 (5.0rdg + 5rdg)
Fundamental frequency: 42  69.0 Hz
Harmonics are zeroed at the below conditions::
 DC : DC value <0.5% fundamental value or DC value < 1.0V
 1° Harmonic: value of 1° Harmonic < 15V
 2nd  49th Harmonics: harmonic value <0.5% fundamental value or if value < 1.0V
Current harmonics
Range [%] Resolution [%] Order Accuracy
0.1  100.0
0.1
DC, 01  49 (5.0rdg + 5rdg)
Fundamental frequency: 42  69.0 Hz
Harmonics are zeroed at the below conditions::
 DC : DC value <0.5% fundamental value or DC value <0.5% FS clamp
 1° Harmonic: value of 1° Harmonic < 0.5% FS clamp
2nd  49th Harmonics: harmonic value <0.5% fundamental value or if value < 0.5% FS clamp
Voltage anomalies (Phase-Neutral, Phase-PE)
Range [V] Resolution [V] Resolution [ms] Accuracy [V] Accuracy [ms]
15.0  380.0
0.2 20ms
(1.0rdg + 2dgt)  1cycle
Voltage anomalies (Phase-Phase)
Range [V] Resolution [V] Resolution [ms] Accuracy [V] Accuracy [ms]
15.0  660
0.2 20ms
(1.0rdg + 2dgt)  1cycle
