GSC60
EN - 107
10.3. REFERENCE GUIDELINES
Safety: IEC/EN61010-1, IEC/EN61557-1, IEC60364
EMC : IEC/EN61326-1
Technical documentation: IEC/EN61187
Safety of measuring accessories: IEC/EN61010-031, IEC/EN61010-2-032
Insulation: double insulation
Pollution level: 2
Max operating altitude: 2000m (6562ft)
Protection index: IP40
Measurement category: CAT IV 300V to ground, CAT III 350V to ground
max 600VAC between inputs
LOW (200mA): IEC/EN61557-4
M: IEC/EN61557-2
RCD: IEC/EN61557-6 (only on Phase-Neutral-Earth systems)
LOOP P-P, P-N, P-PE: IEC/EN61557-3
EARTH: IEC/EN61557-5
123: IEC/EN61557-7
Multifunction: IEC/EN61557-10
Short circuit current : EN60909-0
Earth resistance TN system: EN61936-1 + EN50522 (no USA, Germany, Extra Europe)
Network quality: EN50160
10.4. GENERAL CHARACTERISTICS
Mechanical characteristics
Size (L x W x H): 225 x 165 x 75mm ; (9 x 6 x 3in)
Weight (batteries included): 1.2kg ; (42 ounces)
Power supply
Battery type: 6 x1.2V rechargeable batteries NiMH type AA
6x1.5V alkaline batteries type AA IEC LR06 MN1500
Low battery indication: low battery symbol “
” on the display
Battery life: > 500 tests for each function
> 6 hours in recording
Recharging time: approx. 12 hours
External adapter: 100-240VAC, 50/60Hz / 15VDC, CAT IV 300V
Auto Power OFF: after 5 minutes idling (if activated)
Miscellaneous
Display: TFT, color, capacitive touch-screen, 320x240mm
Memory for safety test: 999 memory locations, 3 levels of markers
Memory for recordings: 8MB (not expandible)
Connection to PC: optical/USB port
Remote connection: WiFi connection
