HT GSC60 - Technical Characteristics PQA Section

GSC60
EN - 105
Environmental parameters
Measurement Range Resolution Accuracy
°C
-20.0
 60.0°C
0.1°C
(2%rdg + 2digits)
°F
-4.0
 140.0°F
0.1°F
RH%
0.0%
 100.0%RH
0.1%RH
DC voltage
0.1mV
 1.0V
0.1mV
Lux
0.001
 20.00lux (*) 0.001  0.02Lux
0.1  2.0klux (*) 0.1  2Lux
1  20.0klux (*) 1  20Lux
(*) Accuracy of the luxmetric probe according to Class AA
10.2.
TECHNICAL CHARACTERISTICS PQA SECTION
DC/AC TRMS Voltage (Phase-Neutral)
Range [V] Resolution [V] Accuracy
15.0  380.0
0.1V
(1.0rdg + 1dgt)
Crest factor:  1,5 ; Frequency: 42  69.0 Hz
DC/AC TRMS Voltage (Phase-Phase)
Range [V] Resolution [V] Accuracy
15.0  660.0
0.1V
(1.0rdg + 1dgt)
Crest factor:  1,5 ; Frequency: 42  69.0 Hz
Frequency
Range [Hz] Resolution [Hz] Accuracy
DC, 42  69.0
0.01
(2.0rdg + 2dgt)
Allowed voltage: 15.0  660V ; Allowed current: 5%FS clamp  FS clamp
DC/AC TRMS Current (STD clamp)
FS clamp Range [A] Resolution [A] Accuracy
 10A 5% FS  9.99
0.01
(1.0rdg + 3 dgt)
10A  FS  300 5% FS  299.9
0.1
300A  FS  3000 5% FS  2999
1
Range: 5  999.9 mV, values under 5mV are zeroed, Crest factor:  2.4; Frequency: 42  69.0 Hz
AC TRMS Current (FLEX Clamp - 300A AC range)
Range [mV] Frequency [Hz] Resolution Accuracy Overload protection
0.085  85.0 42  65.0 8.5V (0.5rdg+0.17%FS)
10V
Crest factor 3 . Allowed current <1A are zeroed
AC TRMS Current (FLEX Clamp - 3000A AC range)
Range [mV] Frequency [Hz] Resolution Accuracy Overload protection
0.425  255.0 42  65.0 85V (0.5lettura+0.17%FS)
10V
Crest factor 3 . Allowed current <5A are zeroed
DC Power
FS clamp Range [kW] Resolution [kW] Accuracy
≤10A
0.000  9.999
10.00  99.99
0.001
0.01
(2.0rdg + 7dgt)
10A < FS ≤ 200A
0.00  99.99
100.0  999.9
0.01
0.1
200A < FS ≤ 1000A
0.0  999.9
1000  9999
0.1
1
1000A < FS ≤ 3000A
0  9999
1
