GSC60
EN - 138
HARM
Description Settings
System type: Not modified
Frequency: Not modified
Clamp type: Not modified
Full scale clamp: Not modified
TV ratio: Not modified
Start recording: Not modified
Stop recording: Not modified
Aggregation time: 10min
Voltage anomalies recordings: Selected
Reference voltage anomalies (Vn): Not modified
High threshold limit for voltage anomalies: Not modified
Low threshold limit for voltage anomalies: Not modified
Harmonic s recording: Selected
Selected voltage: V1(Single); V12,V32,V31(3-wires); V1,V2,V3 (4-wires)
Voltage harmonics::
THD%,DC,01,02… 49
Voltage unbalance: Not selected
Voltage frequency: Selected
Selected current I1 (Single); I1,I2,I3 (3-wires); I1,I2,I3,In (4-wires)
Current harmonics:
THD%,DC,01,02… 49
Powers, energie, power factors: Not selected
Table 9: List of parameters saved in HARMONICS typical configuration
