GSC60
EN - 76
3 Move the left slide bar cursor in order to select the
aggregation time (see § 12.17) among the options: 2s,
5s, 10s, 30s, 1min, 2min, 5min, 10min, 15min, 30min
Move the central slide bar cursor (“GO” symbol) to the
positions:
Manual start of recording by pressing the
GO/STOP key (at the next minute after the pressure
of key)
Automatic start of recording at the date/time
set by the user (after a preliminary pressure of
GO/STOP key in order to set the instrument in
stand-by mode). Touch the corresponding field to
set the date/time in the “MM:DD:YY HH:MM”
format and confirm
Move the right slide bar cursor (“STOP” symbol) in the
positions:
Manual stop of recording by pressing the
GO/STOP key
Automatic stop of recording at the date/time
set by the user. Touch the corresponding field to
set the date/time in the “MM:DD:YY HH:MM”
format and confirm
4
Insert in the auxiliary I1 input the transducer necessary for the desired measurement as
shown in Fig. 32
5 The measured value appears on the display in real time
as shown in the screen to the side.
Press the SAVE button or touch the icon to save
the measurement (see § 7.1).
