Phone Basics 29
To install the battery
Align the battery’s exposed
copper contacts with the battery
connectors inside the battery
compartment.
Insert the contact side of the
battery first then gently push the
battery into place.
Replace the back cover.
1.
2.
3.
Battery contacts
To remove the battery
Make sure the phone is turned off.
Remove the back cover.
Lift up the battery from the small
opening at the top of the battery
compartment.
1.
2.
3.
Lift up from here
