Figure 13-12 Installing the adapting piece for the GPS surge protector
2. Secure the GPS surge protector to the adapting piece. That is, pre-tighten the GPS surge
protector with hands, and then use an adjustable wrench to tighten it, as shown in Figure
13-13.
Figure 13-13 Installing the GPS surge protector
3. Install the GPS clock signal cable on the GPS surge protector, as shown in Figure 13-14.
DBS3900 (Ver.B)
Installation Guide 13 Indoor Scenario (BBU Installed in an IMB03)
Issue 06 (2011-09-15) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
443
