FusionModule5000 Smart Modular Data Center
Maintenance Guide (ECC800)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 5-42 Removing the locating pin
The valve port of the T water valve body faces left, and the connecting plate is fitted in with
the screws on the left. The handle is kept upwards.
2. Place the valve port of the T water valve body facing left, as shown by (1) in Figure 5-43.
Fit in the connecting plate with the screws on the left, as shown by (3) in Figure 5-43.
Keep the handle upwards, as shown by (4) in Figure 5-43.
