Huawei FusionModule800 Maintenance Guide

FusionModule800 Smart Small Data Center
Maintenance Guide
2 O&M Preparations
Issue 02 (2016-11-15)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
2
2 O&M Preparations
2.1 Obtaining Technical Documents
Before maintenance, prepare the following documents in addition to this document.
Table 2-1 Maintenance documents
Document
Function
Obtaining Method
(Remarks)
Electrical Conceptual
Diagram
Describes the control
relationship of the power
distribution system.
See the documents delivered
with the IDS800.
FusionModule800 Smart
Small Data Center
V100R001 Installation
Guide
Provides guidance about
Smart Module installation
and commissioning.
Downloaded from
http://support.huawei.com
UPS2000-G-(6 kVA-20 kVA)
User Manual
Describes the UPS
installation, operation, and
maintenance.
Downloaded from
http://support.huawei.com
RMS-MODBUS01A User
Manual
Describes the Modbus card
installation, operation, and
maintenance.
Downloaded from
http://support.huawei.com
2.2 Tools
Table 2-2 Tools and instruments
Tool Name, Specifications, and Appearance
Protective insulation
gloves
Step ladder (2 m)
Phillips screwdriver
M4/M6/M8
Flat-head
screwdriver
