Figure 2-5 GP316 components
1 GP316 case 2 PCIe board
3 PCIe switches 4 Riser card trays
5 Half-height half-length single-width
cards
6 Riser cards
For details about the supported components and their BOM numbers, see Server
Compatibility Checker.
2.2 Front Panel Components
Figure 2-6 shows front panel components of a full-width compute node.
